Products / Sanitation trucks / Electric Road-Maintenance Cleaning Vehicle
CORLIR · NEW ENERGY SERIES
Electric Road-Maintenance Cleaning Vehicle
An electric road-cleaning and maintenance vehicle for urban pavements and public spaces, combining conventional cleaning functions with low-noise electric drive.
Product features
01
Electric chassis and optimized body
02
Independent water systems
03
Flexible cleaning modes
04
Reliable key components
Operating functions & vehicle details
Technical specifications
Compare the available chassis configurations.
Configuration group 1
| Item | Xiaoshentong | Dongfeng Tuyi | SAIC Yuejin | SAIC Yuejin |
|---|---|---|---|---|
| Chassis brand | Tangjun Ouling | Dongfeng | Yuejin | Yuejin |
| Capacity (L) † | 800 | 2 | 1.5 | 2 |
| Gross mass (kg) | 950 | 4495 | 3250 | 4495 |
| Wheelbase (mm) | 2200 | 2800 | 2500 | 2850 |
| Battery type | LFP | CATL LFP | CATL LFP | CATL LFP |
| Battery capacity(kWh) | 6.9/8.4 | 55.7 | 41.86 | 66.8 |
| Charging time(min) | Slow 240–300 | Fast 40 | Fast 60 | Fast 90 |
| Range (km) | 115 | 220 | 260 | 260 |
| Washing width (m) | 1 | 1.3 | 1.3 | 1.5 |
| Max. washing pressure | 10 | 15 | 15 | 15 |
| High-pressure capacity | 13000 | 26000 | 26000 | 26000 |
| Water-gun range (m) | 10 | 10 | 10 | 10 |
| Cleaning speed | 5-25 | 5-25 | 5-25 | 5-25 |
Configuration group 2
| Item | Foton Linghang S1 | SAIC Yuejin | Dongfeng Tianjin |
|---|---|---|---|
| Chassis brand | Foton | Yuejin | Tianjin |
| Capacity (m³) | 2 | 5 | 12 |
| Gross mass (kg) | 4495 | 12495 | 18000 |
| Wheelbase (mm) | 2850 | 4170 | 5300 |
| Battery type | CATL LFP | CATL LFP | CATL LFP |
| Battery capacity(kWh) | 66.8 | — | 282 |
| Charging time(min) | Fast 50 | — | Fast 72 |
| Range (km) | 280 | — | 183 |
| Front flushingwidth (m) | 1.5 | 2.5-3.5 | 2.5-3.5 |
| Rear sprinkling coverage (m³) † | 15 | 15 | 16 |
| Side spray-bar width (m) | 26000 | 26000 | 28000 |
| Water-cannonrange (m) | 10 | — | — |
| Fog-cannon range (m) | 5-25 | 5-25 | 5-25 |
— Not specified. Values are reproduced as listed in the product catalogue. † Capacity and working-performance units require confirmation. Please confirm missing data, units and final specifications when requesting a quotation.
